48V DC 50W LED Security Flood Light
Model SSSL-FL-48-50
High-Brightness LED Flood Light for Telecom BTS Shelters
Reliable, energy-efficient and maintenance-free lighting that runs directly from your site's 48V DC supply.
Based on Spaceage experience of designing and manufacturing more than 1,25,000 LED Aviation Lights, Spaceage launches the 48V DC LED Security Flood Light, specifically for telecom BTS shelters.
Reliable • Energy Efficient • Long Life • Maintenance Free. Designed to operate directly from the telecom site's 48V DC power supply. We have 24V DC and 230V AC models also.
Get a Quote +91 99277 50807
Features of the 48V DC LED Security Flood Light
Designed to operate directly from the telecom site's 48V DC power supply. 24V option also available.
Provides 80 lux at 3 metres (750 lux at 1 m) stable illumination across 48V to 56V DC.
Equipped with 64 high-power 1W LEDs sourced from reputed LED manufacturers for high luminous output and dependable long-term performance. By using 64 LEDs instead of the industry-standard 50 LEDs, the light remains cool.
High-quality LEDs with a rated life of up to 100,000 hours, significantly reducing maintenance and replacement requirements.
The light is designed with an efficient thermal management system to keep the LEDs operating at controlled temperatures, helping maintain long LED life and stable brightness.
Produces bright white illumination suitable for BTS shelters and surrounding zones.
*LED life is dependent on operating temperature, electrical conditions and installation environment.
Technical Highlights
| Parameter | Specification |
|---|---|
| Model No. | SSSL-FL-48-50 |
| Input Voltage | 48V DC nominal |
| Operating Voltage | 48-56V DC |
| Power Supply | 48V - 56V DC |
| Wattage | 50 W |
| Light Source | 64 high-power LEDs |
| LED Type | Bridgelux 1 W LED (64 nos.) |
| Light Colour | White |
| Colour Temperature | 2700 to 6500 K |
| Luminous Flux | 5000 to 6000 lumens |
| Brightness | 80 lux at 3 m (750 lux at 1 m), stable across 48-56V DC |
| Beam Angle | 90 to 160 degrees |
| Colour Rendering Index | Ra > 80 |
| LED Life | Up to 100,000 hours* |
| Usage | 10 to 12 hours / day |
| Ingress Protection | IP66 |
| Optics | Full glass |
| Luminaire Casing | Water-proof aluminium body |
| Cooling | Designed for low-temperature operation |
| Heat Sink | In-built in body |
| LED Thermal Management | Fins to dissipate the heat to ambient air |
| Operating Temperature | -20 to 60 deg C |
| Operating Humidity | 85% non-condensing |
| Total Harmonic Distortion | < 15% |
| System Power Efficiency | > 85% |
| Lamp Starting Time | Not more than 5 seconds |
| Energy Consumption | Not more than 1.2 times at rated voltage |
| Control Circuit | Compatible to LED |
| Application | Telecom BTS / Security Lighting |
Due to continuous development, Spaceage reserves the right to modify specifications at any time without prior notice.
