Medium Intensity type B 230V AC Aviation Light Dual Dome STANDBY with FAULT Monitoring

SPECIFICATIONS FOR MEDIUM INTENSITY TYPE - B AVIATION OBSTRUCTION LAMPS
Product code : SSSL-MB-A (For 230V AC Input) SSSL-MB-D (For 48V DC input)
Type of light : LED Light
Supply Voltage : 48V DC +/- 10% (for SSSL-MB-A) 230V AC +/- 10% (for SSSL-MB-D)
Light Intensity : >2000 Candelas (Cd)
Light Spread : As per ICAO norms
ICAO Compliant : Yes, compliant with Medium intensity Type B specifications
Inbuilt Photo Sensor : Yes, for Auto ON/OFF Control based on ambient light
Flashing : Yes
Flashing frequency : 20-60 flashes per minute
Light Source : 480 No.s High Power Light Emitting Diodes (LED) from reputed sources
LED Color : Red
LED Life : 50,000 Hours
LED Clusters in parallel : 120 parallel circuits
Power Consumption : 30W Peak, 15W Average
Power Factor : >0.95
Dome Material : Clear Glass Dome (that does not deteriorate like plastics do)
Base material : High grade Cast Aluminum
Finish : Orange color Epoxy Powder coated on Aluminum base
Environmental Protection : IP65
Bird Spike : Yes, built-in
Operating Temperature : -10°C to +60°C
Mountings : Drill/Weld free Mounting arrangement provided

Note: Due to continuous improvements Spaceage reserves the right to modify the specs
